Aritonang, Bernhard Petrus (2018) Perancangan Battery Control Unit (Bcu) Dengan Pid Controller Pada Sistem Tenaga Surya. Sarjana thesis, Universitas Brawijaya.
Abstract
Solar energy is one of the most abundant renewable energy supplies in Indonesia, so it can be utilized to generate electricity by applying a solar power installation system. Solar panels are converting solar energy into electricity and batteries as energy storage devices. However, the varying intensity of sunlight can cause the battery to break down quickly because the currents and voltage entering the battery are not constant. This research tries to give solution to the problem by making buck-boost converter tool by applying proportional intergral derivative (PID) control method. Buck boost converter is used because the output voltage can be increased or decreased even though the input voltage is variable. PID controller is chosen because this method can keep the system output more stable by processing the system error. The system is created using Arduino uno as the controller, IC Xl6009 as Buck boost converter, and uses a voltage sensor to measure the output side of the system. The root locus method is used to specify PID parameters. Parameter obtained ie Kp = 3.24, Ki = 0.5 and Kd = 4.76. The whole system test shows the output the system has a delay time (td) of 0.09s, rise time (tr) of 0.23s, peak time (tp) of 0.4s, settling time (ts) of 0.5s, 5% overshoot, output error is only 0.54% and recovery time of 0.3s
English Abstract
Energi matahari merupakan salah satu energi terbarukan yang melimpah persediaannya di Indonesia, sehingga dapat dimanfaatkan untuk menhasilkan listrik dengan cara menerapkan sistem instalasi tenaga surya. Panel surya berperam mengubah energi matahari menjadi energi listrik dan baterai sebagai media penyimpan energi tersebut. Namun, intensitas cahaya matahari yang berubah-ubah dapat menyebabkan baterai cepat rusak karena arus dan tegangan yang masuk ke baterai tidak konstan. Penelitian ini mencoba untuk memberikan solusi terhadap permsalahan tersebut dengan cara membuat alat bertopologi buck-boost converter dengan menerapkan metode kontrol proportional integral derivative (PID). Buck boost converter digunakan karena tegangan output dapat dinaikan atau diturunkan meski tegangan input berubah-ubah. PID controller dipilih karena metode ini dapat menjaga output sistem lebih stabil dengan mengolah error sistem. Sistem yang dibuat menggunakan Arduino uno sebagai controller, IC Xl6009 sebagai Buck boost converter, dan menggunakan sensor tegangan untuk mengukur sisi output sistem. Metode root locus digunakan untuk menentukan parameter PID. Parameter didapatkan yaitu Kp=3.24, Ki=0.5 dan Kd=4.76. Pengujian keseluruhan sistem menunjukan output sistem memiliki delay time (td) sebesar 0.09s, rise time (tr) sebesar 0.23s, peak time (tp) sebesar 0.4s, settling time (ts) sebesar 0.5s, 5% overshoot, error output hanya 0.54% dan recovery time sebesar 0.3s
Other obstract
-
| Item Type: | Thesis (Sarjana) |
|---|---|
| Identification Number: | SKR/FT/2018/916/052000300 |
| Uncontrolled Keywords: | Energy, Battery, Buck-boost converter, PID controller, Energi, Baterai, Buck-boost converter, PID controller |
| Subjects: | 600 Technology (Applied sciences) > 621 Applied physics > 621.3 Electrical, magnetic, optical, communications, computer engineering; electronics, lighting > 621.38 Electronics, communications engineering > 621.381 Electronics > 621.381 5 Components and circuits > 621.381 53 Printed circuits and circuits for specific functions > 621.381 535 Amplifiers and feedback circuits > 621.381 537 Switching, control, trigger circuits, relays |
| Divisions: | Fakultas Teknik > Teknik Elektro |
| Depositing User: | Nur Cholis |
| Date Deposited: | 10 Aug 2020 07:29 |
| Last Modified: | 24 Oct 2021 13:21 |
| URI: | http://repository.ub.ac.id/id/eprint/178716 |
